1. Such Dir zuerst Dein Resin aus
  2. Finde Deinen Drucker
  3. Entnehme aus der Tabelle unsere Parameter-Empfehlung

Wähle das gewünschte InovaPrint Resin in den Einstellungen der Alpha AI-Software

Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
0.100 5,0 – 6,0 4 50 1 0 10 7 5 40 180 100%
0,070 4,5 – 5,5 4 45 1 0 10 7 5 40 180 100%
0.050 4,0 – 5,0 4 40 1 0 10 7 5 40 180 100%
Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
0.100 7,0 – 8,0 4 35 11,5 0 10 7 5 40 180
0,070 6,5 – 7,5 4 30 11,5 0 10 7 5 40 180
0.050 5,5 – 6,5 4 25 11,5 0 10 7 5 40 180
Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
0.100 19,0 – 22,0 4 120 1 0 10 7 5 40 180
0.070 17,0 – 20,0 4 110 1 0 10 7 5 40 180
0.050 15,0 – 18,0 4 100 1 0 10 7 5 40 180
Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
0.100 6,0 – 7,0 4 30 11,5 0 10 7 5 40 180
0.070 4,5 – 5,5 4 25 11,5 0 10 7 5 40 180
0.050 3,5 – 4,5 4 20 11,5 0 10 7 5 40 180

Wähle das gewünschte InovaPrint Resin in den Einstellungen der Alpha AI-Software

Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
0.100 6,0 – 7,0 4 50 1 0 10 7 5 40 180 100%
0,070 5,0 – 6,0 4 45 1 0 10 7 5 40 180 100%
0.050 4,5 – 5,5 4 40 1 0 10 7 5 40 180 100%
Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
0.100 5,0 – 6,0 4 35 11,5 0 10 7 5 40 180
0,070 4,5 -5,5 4 30 11,5 0 10 7 5 40 180
0.050 4,0 – 5,0 4 25 11,5 0 10 7 5 40 180
Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
0.100 14,0 – 15,0 4 120 1 0 10 7 5 40 180
0.070 12,0 – 13,0 4 110 1 0 10 7 5 40 180
0.050 10,0 – 11,0 4 100 1 0 10 7 5 40 180
Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
0.100 4,0 – 5,0 4 30 11,5 0 10 7 5 40 180
0.070 3,0 – 4,0 4 25 11,5 0 10 7 5 40 180
0.050 2,5 – 3,0 4 20 11,5 0 10 7 5 40 180
